HBL5269C - Conn, 15A 125V, 5-15R, B/W

WDK

$37.81 (Each)
$37.81 (Each)
$378.10 (Per 10)

In-Stock: 114 available at other locations ( find a store with stock)

Buy Now

QTY:

Each

Also in stock

$2,266.58Per 100

PS5269X

Pass & Seymour/Legrand
Straight Blade Conn 3W 15A 125V B&W

View Item or Compare

Overview
Specifications
Current Stock
Alternate Items

Overview

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Help Improve Our Data

Quick Specs

Catalog Number: HBL5269C Vendor Code HWD
Manufacturer: WDK
Manufacturer's Part Number: HBL5269C
Description: Conn, 15A 125V, 5-15R, B/W
Straight Blade Device Connector, 15 A, 125 V Ac, 2 Poles, 3 Wires, Black/White, -40 °C Operating Temperature, +75 °C Operating Temperature, Screw/Clamp Terminal, 1.527 In Diameter, Cord Mounted, 2.78 In Length, #18 to #8 Awg (Copper Conductor) Wire Size, Impact and Chemical Resistant, 0.15 LB
Slang Terms: Suggest a New Term
Categories: Gen Purpose Wiring Devices - Plugs, Connectors, Inlets, Out Mark as Incorrect
Suggest a New Category
Classification: Commercial Cord Connectors
UNSPSC: 39121421 - Electrical connector assembly
UPC/EAN/GTIN: 783585173252 / 0783585173252 / 00783585173252
Weight per unit: 0.2 (lbs/each)

Price & Packaging

Minimum Order Quantity: 1
Unit: $37.81 (Each)
Carton: $378.10 (Per 10)

Stock Availability

Lufkin: 0 (Find nearest stock)
Nacogdoches: 0
All Stores: 114

Resources

Images
: HBL5269C - Small Image
: HBL5269C - Large Image
: HBL5269C - Large Image
: HBL5269C - Large Image
: HBL5269C - Large Image
: HBL5269C - Large Image
: HBL5269C - Large Image
: HBL5269C - Large Image
: HBL5269C - Large Image
: HBL5269C - Large Image
Other Links
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
: HBL5269C - Other
Attachments
: HBL5269C - Specification Sheet
Specifications Sheets
: HBL5269C - Specification Sheet

Suggest Substitute Item

Help Improve Our Data

Edit Mode: Please login to suggest improvements for this item.

Specifications

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Help Improve Our Data

Features

Amperage Rating: 15
Connection: Screw Terminals
Current Rating: 15 A
Insulation: Insulated Body
Material: Nylon (Housing/Cord Clamp, Blade Holder);Clear Polycarbonate (Terminal Retainer);Brass (Contact, Terminal Screws);Nickel Plated Steel (Terminal Clamp, Assembly Screws)
Number Of Conductors: 3
Number Of Wires: 3
Poles: 2-Pole
Terminal Type: Screw;Clamp
Voltage Rating: 125 V ac
Wire Size: #18 to #8 AWG (Copper Conductor)

Material, Color, and Finish

Color: Black;White
Finish: Nickel Plated (Terminal Clamp, Assembly Screw)

Dimensions and Weight

Diameter: 1.527 in;38.78 mm
Length: 2.78 in;70.64 mm
Size: 2.65 in x 1.55 in x 2.65 in

Descriptions

Description: CONN, 15A 125V, 5-15R, B/W
Extra Long Description: HWDK HBL5269C CONN, 15A 125V, 5-15R
Features: Straight Blade Devices, Female Connector Body, Insulgrip Heavy Duty, Industrial/Commercial Grade, Straight, 2- Pole 3-Wire Grounding, 15A 125V, 5-15R, Black and White, Single Pack.
Long Description: Straight Blade Device Connector, 15 A, 125 V ac, 2 Poles, 3 Wires, Black/White, -40 °C Operating Temperature, +75 °C Operating Temperature, Screw/Clamp Terminal, 1.527 in Diameter, Cord Mounted, 2.78 in Length, #18 to #8 AWG (Copper Conductor) Wire Size, Impact and Chemical Resistant, 0.15 lb
Product Type: Straight Blade Device Connector
Short Description: Straight Blade Device Connector, 15 A, 125 VAC, Black;White
Special Features: Individual Wiring Terminals Completely Enclosed;Fast Lead Assembly Screws;Beveled Housing Prevents Snagging

Additional Information

Maximum Operating Temperature: +75 °C
Minimum Operating Temperature: -40 °C
Mounting Type: Cord Mounted
Package Quantity: 1 CT;10 PK
Pallet Quantity: 6600
Resistance Properties: Impact and Chemical Resistant
Standards Met: UL 498 Listed;UL FS WC596;CSA Certified C22.2

Manufacturer Information

Brand: Hubbell Wiring Devices
Manufacturers Part Number: HBL5269C
Series: Insulgrip® Series
GTIN: 00783585173252
UPC: 783585173252

Taxonomies, Classifications, and Categories

Category Description: Commercial cord connectors
Type: Connector Body

Packaging

Weight: 0.15 lb
Weight per each: 0.2
Carton: 10

Uses, Certifications, and Standards

Application: Industrial/Commercial
Environmental Conditions: Indoor Dry unless protected by additional means
Mounting: Cord
Nema Rating: NEMA 5-15R
Standard: CSA Certified to C22.2 No. 42 File 280;NEMA® WD-6 Compliant;UL Listed to UL498 File E1706
